Technical Specifications
Model | SBK 10-3/3 |
Brand | Gol Pumps |
Manufacturer’s Warranty | 1 year Limited Warranty |
Chamber Complete Impeller Neck Ring Priming Screw Strainer Pump Head Pump Shaft | Stainless Steel 304 Stainless Steel 304 PTFE Stainless Steel 304 Stainless Steel 304 Stainless Steel 304 Stainless Steel 431 |
Shaft seal
| SUUV S (O-ring seal cartilage type) U (Tungsten Carbide) V (VITON) |
Flow (GPH) | 4140 |
HP Kw | 3 2.2 |
Volts | 230-460 V – Three phase – 60 Hz |
Amps | — |
Max. Total Head (ft.) | 144 |
Max. Suction Lift (ft.) | — |
Max. PSI | 62 |
Self-Priming | No |
Centrifugal | Yes |
Dimensions L x W x H (in.) | 10.4 x 7 x 24 |
Product Weight (lbs.) | 74 |
