Coolant Immersible Vertical Multi-Stage Water Pump — 6300 GPH, 10HP, 230-460V – 60 Hz – 3PH – SBK 15-5/5

5/5

Coolant Immersible Vertical Multi-Stage Water Pump — 6300 GPH, 10HP, 230-460V – 60 Hz – 3PH – SBK 15-5/5

AC/DC Pumps

Category AC Pumps

Brand

Gol Pumps

AC Voltage

208-220 volts, 440-480 volts

Horsepower

10

Phase

$5,040.99

SBKI pumps are vertical multistage centrifugal pumps especially designed for pumping of cooling lubricants for machine tools , and to be mounted on top of tanks with the pump stack immerged in the pumped liquid.

Applications

  • Cooling units
  • Grinding machines
  • Machine centers
  • Spark machine tools
  • Filtering systems
  • Milling machines
  • Boring machines
  • Drilling machines
  • Filtering systems
  • Swarf conveyors
  • Industrial washing machines

Features

  • Compact design
  • High Efficiency Reliability
  • Easy installation
  • Flexible installation length
  • Wide performance range
  • Reliability
  • Service-friendly

Motor Data

  • SBK is fitted with totally enclosed fan-cooled, 2-pole standard motor.
  • Rated speed: 3450rpm(60Hz)
  • Enclosure class: IP 55
  • Insulation class: F
  • Ambient Temperature Max: +122°F

Pumped Liquids

  • Do not pump the explosive or aggressive liquids and the liquids should be free of fibers. The SBK pumps have the strainer in the suction chamber with inlet to prevent large particles from entering and damaging the pump.
  • In order to avoid the larger particles block the filters, we suggest to filtrate elementarily before pumping the liquids with particles.

Mechanical Seals

  • Standard Cartridge type mechanical seal made of Tungsten carbide / Tungsten carbide Viton.
  • The cartridge type mechanical seal can be replaced in minutes without special tools and without dismantling the pump.



Estimated Delivery Time: 3 – 5 Business Days

  *If the item is over 100 lbs, forklift is required at commercial delivery location only, otherwise we will charge $100 Liftgate service fee . For residential addresses additional delivery fees may apply

Technical Specifications

ModelSBK 15-5/5
BrandGol Pumps
Manufacturer’s Warranty1 year Limited Warranty
Chamber Complete

Bearing Ring

Impeller

Neck Ring

Priming Screw

Strainer

Pump Head

Pump Shaft

Motor stool

Stainless Steel 304

Sic

Stainless Steel 304

PTFE

Stainless Steel 304

Stainless Steel 304

Cast-iron

Stainless Steel 431

Cast-iron

Shaft seal







SUUV

S (O-ring seal cartilage type)

U (Tungsten Carbide)

V (VITON)

Flow (GPH)6300
HP

Kw

10

7.5

Volts230-460 V – Three phase – 60 Hz
Amps
Max. Total Head (ft.)331
Max. Suction Lift (ft.)
Max. PSI143
Self-PrimingNo
CentrifugalYes
Dimensions L x W x H (in.)12.6 x 9.2 x 34.7
Product Weight (lbs.)181.2
