SAER M202 Convertible Deep Well Jet Pump – 2HP – 792 GPH
5/5
SAER M202 Convertible Deep Well Jet Pump – 2HP – 792 GPH
Free Shipping
Additional information
| Dimensions | 13 × 8.5 × 9.2 in |
|---|---|
| AC/DC Pumps | AC |
| Horsepower | 2 |
| Phase | Single Phase |
| Self-Priming | Self-Priming |
| Voltage | 230 volt |
| Brand | Saer |
| AC Voltage | 110/220 Dual |
| Category AC Pumps | Deep Well Jet Pumps, Garden Pumps, Irrigation Pumps, Residential Pumps, Shallow Well Jet Pumps |
$922.99
This SAER®-USA M202 Convertible Deep Well Jet Pump is a 2HP, convertible, deep Well Jet Pump that is ideal for water transfer, irrigation, heating/cooling systems, industrial applications and more.
- Cast iron body for rugged durability
- Pressed brass impeller provides corrosion resistance
- Totally enclosed fan-cooled motor
Estimated Delivery Time: 3 – 5 Business Days
*If the item is over 100 lbs, forklift is required at commercial delivery location only, otherwise we will charge $100 Liftgate service fee . For residential addresses additional delivery fees may apply
Description
Applications
The SAER Convertible Deep Well Jet M202 , 2 HP , 1 PH , 230-Volt, 60 HZ , NPT TREAD , BRASS & CAST-IRON IMPELLER. General water supply, pressurization of water by using pressure, vessels (autoclaves) horticultural irrigation, mist irrigation, dairy, farm also industrial applications. Water transfer and garden watering applications. Maximum lift is 49 ft. and Maximum flow 792 GPH.(With External Ejector For Deep Wells 4″)
Features
- Cast iron body for rugged durability
- Pressed brass impeller provides corrosion resistance
- Carbon/ceramic mechanical seal for wear resistance and long life
- Stainless steel rotor shaft is strong and resists corrosion
- Totally enclosed fan-cooled motor
More Details
- Diffuser in thermoplastic resin
- Mechanical seal in carbon/ceramic
- Maximum temperature of pumped liquid 5°F to 122°F
- Maximum working pressure 130.5 psi
- Maximum ambient temperature 104°F; for higher temperatures
- Ejector Type: P1/20
Technical Specifications
| Model | M-202 |
| Brand | Saer-USA |
| Manufacturer’s Warranty | 1 year Limited Warranty |
| Impeller Material | Brass |
| Port Size (in.) | 1″ |
| Flow (GPH) | 792 GPH |
| HP | 2HP |
| Volts | 230V – 1 Phase |
| Max. Total Head (ft.) | 243ft |
| Max. Suction Lift (ft.) | 49ft |
| Max. PSI | 107.3psi |
| Suction Port (in.) | 1.25″ |
| Discharge Port (in.) | 1″ |
| Self-Priming | Yes |
| Dimensions L x W x H (in.) | 13″ x 8.5″ x 9.2″ |
| Product Weight (lbs.) |
Downloadable Information
Additional information
| Dimensions | 13 × 8.5 × 9.2 in |
|---|---|
| AC/DC Pumps | AC |
| Horsepower | 2 |
| Phase | Single Phase |
| Self-Priming | Self-Priming |
| Voltage | 230 volt |
| Brand | Saer |
| AC Voltage | 110/220 Dual |
| Category AC Pumps | Deep Well Jet Pumps, Garden Pumps, Irrigation Pumps, Residential Pumps, Shallow Well Jet Pumps |
